Trip unit TM80DC, ComPacT NSX 100 DC, thermal magnetic, 80A rating, 3 Poles 3d

Trip unit TM80DC, ComPacT NSX 100 DC, thermal magnetic, 80A rating, 3 Poles 3d

by Schneider Electric
SKU C103TM080D
Availability:
Available for backorder
Available for backorder
R 2,265.33 - R 2,265.33
R 2,265.33
R 2,265.33 - R 2,265.33
R 2,265.33

TM80DC is a 3 poles thermal-magnetic trip unit used on ComPacT NSX 100DC circuit breakers. This 80A rating thermal-magnetic trip unit is an optimum choice for all distribution applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. The rated current is 80A and the operational voltage is 750VDC. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

Product Highlights

  • Schneider Electric green signature style for the entire ComPacT range
  • Estimated 40% reduction of wiring time for panel builders
  • Experience easier installation thanks to a new ergonomic front-plate design
  • Gain the confidence that all auxiliaries are on the right spot, and check that you have the right coil rating
  • Ergonomic new toggle for easier breaker manual operation

For full spec sheet download please click here or contact our support team.
